EPS619
FOTMA
9031809090
| Item no. | Model | EPS611 | EPS615 | EPS619 |
| 1 | Power of test bench | 11kw | 15kw | 18.5kw |
| 2 | Rotation speed range of output shaft | 0-4000 | 0-4000 | 0-4000 |
| 3 | Number of cylinders in test | 12 | 12 | 12 |
| 4 | Times of measurement of fuel | 0-9999 | 0-9999 | 0-9999 |
| 5 | Pressure of fuel(Mpa) | 0-0.04 0-4 | 0-0.04 0-4 | 0-0.04 0-4 |
| 6 | Fuel delivery of fuel pump (L/m) | 25 | 25 | 25 |
| 7 | Height of center of main shaft(mm) | 125 | 125 | 125 |
| 8 | Type of electric motor | Y180M-4 | Y180M-4 | Y180M-4 |
| 9 | Return measurement (L/m) | 10-100 | 10-100 | 10-100 |
| 10 | DC power source | 12V/24V | 12V/24V | 12V/24V |
| 11 | Drive coupling | Several clutches without gap | Several clutches without gap | Several clutches without gap |
| 12 | Grease-box (special accessories) | 12L | 12L | 12L |
| 13 | Pressure of lubricating oil (Mpa) | 0-0.6 | 0-0.6 | 0-0.6 |
| 14 | Degree of vacuum (Mpa) | -0.1-0 | -0.1-0 | -0.1-0 |
| 15 | Air pressure (Mpa) | 0-0.25 | 0-0.25 | 0-0.25 |
| 16 | Pressure of lubricating oil (Mpa) | 0-1.6 | 0-1.6 | 0-1.6 |
| 17 | Cooling methods | Compressor or water cooling | Compressor or water cooling | Compressor or water cooling |
| 18 | Temperature control range | 30-49（±2℃） | 30-49（±2℃） | 30-49（±2℃） |
| 19 | Output power (KW) | 11 | 11 | 11 |
| 20 | Cubage of measurement cylinder (ml) | 45 / 150/260 | 45 / 150/260 | 45 / 150/260 |
| 21 | Dimension of test bench | （L*W*H）2.3*1.05*1.8 | （L*W*H）2.3*1.05*1.8 | （L*W*H）2.3*1.05*1.8 |
| 22 | Weight (KG) | 1200 | 1250 | 1300 |
