PQ400 Double Spring Nozzle Tester

PQ400 Double Spring Nozzle Tester
Quantity:
Introduce:
Our highly efficient injector nozzle tester is made available at best competitive prices. We are widely exporting to places like Canada, USA, Tanzania, Indonesia, Singapore, South America and Middle East.

PQ400 Injector tester.JPG

Main Button:
A: Internal pressure meter
B: Air supply meter
C: Air supply throttle
If the throttle whirls in clockwise, quantity of air input will be less, and oil input is less as well. Inverse, the input oil will increase.
D: Governor valve
If the governor valve circumgyrate to the bottom, rate of oil pressure and air pressure is 100:1. For example, when air pressure 7kg, the oil pressure will be 700kg.
E: Air switch valve
The air valve is opened by pulling, and closed by pushing.
